CE Certified 1.5 Ton Mini Excavator

Qingdao Fullwin Machinery Co., Ltd.
Contact Now

CE Certified 1.5 Ton Mini Excavator

Brand Name : None

Model Number : FW15

Certification : CE/ISO9001: 2000/EPA/Euro 5/SGS

Place of Origin : Shandong, China

Payment Terms : L/C, T/T, Western Union, MoneyGram, D/P, Paypal

Supply Ability : 5000 Units/Year

Delivery Time : 3-15 week days

Packaging Details : Nude / Wooden Box

Drive Type : Internal Combustion Drive

Type : Crawler Excavator

Transmission : Hydraulic Transmission

Customized : Support OEM and ODM

After-sales Service : Spare Parts

Warranty : 12 Months

Bucket Capacity : 0.1-0.5m³

Transport Package : Nude / Wooden Box

Specification : 1500kg

Color : Blue, Yellow, Red, Orange, Green, White

Working Hour : 2000h

Contact Now

1.5 Ton Digger Machinery Rubber Track Mini Excavator With CE

Company Brief Introduction:

Mini Excavator, Full Energy, You will become a Big Winner!

Our main hot products include Excavators, Mini Excavators, Electric Excavators, Electric Forklifts, Road Rollers, scissors elevators, forklifts, and electric forklifts together with other machinery fields. Through these products, our Mini Excavators sell pretty hotly! Like 0.8T, 1.0T, 1.2T, 1.6T, 1.7T, 1.8T, 2.0T, 3.0T, 4T, 5T, 6T, 10T, 20T, 30T Excavators really win customers’ good likes!
And Also Scissor elevator, like 6 meters, 10 meters, 12 meters really hot as well.
All Products have obtained ISO9001, CE, SGS, EPA, and TUV Certificated.

CE Certified 1.5 Ton Mini Excavator

CE Certified 1.5 Ton Mini Excavator

Specifications:

Specifications
Weight 1500kg
Bucket Width 0.025cbm/120kg
Engine 380mm
Bore Stroke Koop(292F)
Rated Power Two cylinders, water cool
Displacement 14kw/3000r/min
Travel Speed 0.794L
Size 2550*940*1380MM
Wheelbase 770MM
Total Length Of Track 1090MM
Platform Ground Clearance 380MM
Platform Back-Turning Radius 733MM
Chassis Width 940MM
Track Width 180MM
Chassis Ground Clearance 380MM
Track Height 320MM
Max. digging depth 1650mm
Max. vertical digging depth 1375mm
Max. digging height 2610mm
Max. dumping height 1850mm
Max. digging radius on ground 2850mm
Min. rotation radius 1330mm
Max. upgrade height of bulldozer blade 345mm
Max. digging depth of bulldozer blade 255mm

Quick Detail:
1. Powerful Engine, KOOP diesel engine/Euro V engine/EPA certified gasoline /Kubota engine for your choices;


2. Adopt the famous hydraulic Shut-off valve;


3. The boom and the bulldozer oil cylinder are equipped with high-strength cast steel protective plates;


4. Dig-to-blade and dozer float features are easy to clean up;


5. Strong lift and dig performance helps you to get the job done faster;


6. Auger, grab, hydraulic hammer, and narrow bucket can be installed;


7. Hydraulic pilot operation is more flexible and convenient.


Applications:
The main uses of the excavator: in road construction projects to excavate trenches, in construction projects to excavate the foundation, in water conservancy projects to excavate ditches, canals, and dredging rivers, in quarries, open-pit mining, and other projects for the stripping and excavation of ore, etc.; in addition to gravel, coal and other loose materials can be loaded.


Operation: After replacing the working device, it can also be used for lifting, pouring, installation, piling, ramming, and pile pulling.
CE Certified 1.5 Ton Mini Excavator
CE Certified 1.5 Ton Mini Excavator
CE Certified 1.5 Ton Mini Excavator
